Balax
3/4-10 UNC Powdered Metal Tap - Balax 40203-000
MFR# 40203-000Series BX200
$161.71List $207.41
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes4
Thread size3/4-10
Description
The Balax 40203-000 is a 3/4-10 UNC Powdered Metal tap. 4 flutes.
Specifications
ChamferModified Bottoming
Coolant throughNo
Flute directionRight Hand
Flute styleFast
Helix angle45
MaterialPowdered Metal
Material applicationAluminum; Brass; Bronze; Carbon Steel; Copper; Magnesium; Stainless Steel; Wrought Aluminum Alloy; Zinc
Material gradeM42
Number of flutes4
Overall length in4-1/4
OversizeNo
Shank diameter0.5900
Square size0.4420
Thread directionRight Hand
Thread limitH3
Thread size in3/4-10
Thread standardUNC
