De-Sta-Co
Swing Clamp - De-Sta-Co 035-140-290
MFR# 035-140-290
$532.02List $565.20
Save 5%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The De-Sta-Co 035-140-290 is a swing clamp.
Specifications
Action typeDouble
Arm length0.7600
Body diameter1.5700
Body length3.2800
Body thread size2-1/4-16
Body width diameter1.5700
Clamping force lb70.14
Clamping force n312.00
FeaturesSeveral Mounting & Clamping Arm Options; Threaded Body for Through-Hole Mount
Maximum operating pressure bar7.00
Maximum operating pressure psi100
Maximum operating pressure psig100
Minimum operating pressure bar3.00
Mount typeThreaded Body
Operating volume cc32.10
Operating volume cu in1.9600
Operation typeAir
Port size1/8 NPT
Rod diameter0.6300
Swing directionLeft Hand
Total stroke distance1.2000
Vertical stroke distance0.6300
