De-Sta-Co
Toggle Clamp - De-Sta-Co 81L25-10100
MFR# 81L25-10100
$719.84
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The De-Sta-Co 81L25-10100 is a toggle clamp.
Specifications
Air requirement psi20 to 130
Bar end typeClosed
Bar opening degrees90
Bar styleSolid
Cylinder bore size1.5700
D (mm)4.00
E (mm)6.50
F (mm)35.00
G (mm)20.00
Height under bar5.9400
Holding capacity inner lb885.00
H (mm)40.50
Length distance between mount holes0.7900
Maximum additional weight at clamp arm mounted in position x0.22
Maximum clamping torque at 72 psig lb159.00
Mounting hole size (mm)M6x8
Mounting orientationVertical
M (mm)40.00
Overall closed height1.3800
Overall open height7.6900
Port sizeM5
Power typePneumatic
Sensor compatibilityRound; T-Slot
Width distance between mount holes0.5900
