0.1969" HSS Screw Machine Drill Bit, TiN, 130° point - Dormer Pramet 5970493

Dormer Pramet

0.1969" HSS Screw Machine Drill Bit, TiN, 130° point - Dormer Pramet 5970493

MFR# 5970493Series A520

$12.96List $16.62 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Flutes2
CoatingTiN

Description

The Dormer Pramet 5970493 is a 0.1969" HSS Screw Machine drill bit with a TiN finish, 130° point. Suited for steel, stainless steel, cast iron, aluminum & non-ferrous, high-temp alloy. Series A520.

Specifications

Coating finishTiN
Coolant throughNo
Cutting directionRight Hand
Drill bit gradeHeavy Duty
Drill bit size0.1969
Drill bit size range0.1500 to 0.2000
Drill length typeScrew Machine
Drill point angle130
Flute by diameter ratio2.5xD
Flute length (mm)26.00
Flute typeRegular Spiral
Number of flutes2
Overall length2.4409
Point typeWeb-Thinned
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Aluminum & Non-Ferrous; High-Temp Alloy
Shank diameter0.1969
Shank length1.4173
Shank typeStraight
Specification designationDIN
Specification numberDIN 1897
Spiral typeRegular
StandardsDIN 1897
Tool materialHSS
Tool performanceHigh Performance
Web configurationParallel
Web thinningWeb-Thinned
