Emuge
M6x1 Metric Tap, TiCN - Emuge BU539300.0060
MFR# BU539300.0060Series Enorm
$31.78List $37.79
Save 15%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes3
CoatingTiCN
Description
The Emuge BU539300.0060 is a Metric tap with a TiCN finish. 3 flutes.
Specifications
ApplicationBlind Hole Threading
ChamferBottoming
Class of fit6H
Coating finishTiCN
Coolant throughNo
Flute directionRight Hand
Flute styleSpiral
Helix angle35
Material applicationCast Iron; Non-Ferrous Metal; Stainless Steel; Steel
Number of flutes3
Overall length (mm)80.00
OversizeNo
Shank diameter0.2550
Square size0.1910
Tapping depth1.1811
Thread directionRight Hand
Thread length (mm)17.00
Thread pitch (mm)1.00
Thread size (mm)M6x1
Thread standardMetric
