Emuge
M8x1.25 Metric Tap, TiCN - Emuge BU539300.0080
MFR# BU539300.0080Series Enorm
$37.15List $43.73
Save 15%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes3
CoatingTiCN
Description
The Emuge BU539300.0080 is a Metric tap with a TiCN finish. 3 flutes.
Specifications
ApplicationBlind Hole Threading
ChamferBottoming
Class of fit6H
Coating finishTiCN
Coolant throughNo
Flute directionRight Hand
Flute styleSpiral
Helix angle35
Material applicationCast Iron; Non-Ferrous Metal; Stainless Steel; Steel
Number of flutes3
Overall length (mm)90.00
OversizeNo
Shank diameter0.3180
Square size0.2380
Tapping depth1.3780
Thread directionRight Hand
Thread length (mm)20.00
Thread pitch (mm)1.25
Thread size (mm)M8x1.25
Thread standardMetric
