Emuge
#4-40 UNC Tap, TiCN - Emuge BU539300.5003
MFR# BU539300.5003Series Enorm
$31.78List $37.79
Save 15%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes2
Thread size#4-40
CoatingTiCN
Description
The Emuge BU539300.5003 is a #4-40 UNC tap with a TiCN finish. 2 flutes.
Specifications
ApplicationBlind Hole Threading
ChamferBottoming
Class of fit2B/3B
Coating finishTiCN
Coolant throughNo
Flute directionRight Hand
Flute styleSpiral
Helix angle35
Material applicationCast Iron; Non-Ferrous Metal; Stainless Steel; Steel
Number of flutes2
Overall length2.2050
OversizeNo
Shank diameter0.1410
Square size0.1100
Tapping depth0.7090
Threads per inch40
Thread directionRight Hand
Thread length0.4330
Thread size in#4-40
Thread standardUNC
