Emuge
0.2677" Solid Carbide Stub Drill Bit, TiAlN, 140° point - Emuge TA209744.0680
MFR# TA209744.0680Series 3XD Solid
$77.74List $86.65
Save 10%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes2
CoatingTiAlN
Description
The Emuge TA209744.0680 is a 0.2677" Solid Carbide Stub drill bit with a TiAlN finish, 140° point. Series 3XD Solid.
Specifications
Coating finishTiAlN
Coolant throughNo
Cutting directionRight Hand
Drill bit diameter tolerancem7
Drill bit gradeHigh Performance
Drill bit size0.2677
Drill length typeStub
Drill point angle140
Drill point length (mm)1.40
Flute by diameter ratio3xD
Flute length1.3386
Flute typeRegular Spiral
Material gradeSubmicron
Maximum drilling depth (mm)24.00
Number of flutes2
Number of margins1
Overall length3.1102
Point typeSelf Centering
Shank diameter0.3150
Shank length1.4173
Shank typeStraight
Specification designationDIN
Specification numberDIN 6537L
Spiral typeRegular
Tool materialSolid Carbide
Tool performanceHigh Performance
Web configurationTapered
Web thinningWeb-Thinned
