Carbide Insert, Grade IN2005, TiAlN - Ingersoll Cutting Tools 5809778

Ingersoll Cutting Tools

Carbide Insert, Grade IN2005, TiAlN - Ingersoll Cutting Tools 5809778

MFR# 5809778Cat# 47B-5037T8RB06 IN2005Series Chip Surfer

$119.41List $148.00 Save 19%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Flutes4
GradeIN2005
CoatingTiAlN

Description

The Ingersoll Cutting Tools 5809778 is a carbide indexable insert, grade IN2005, TiAlN coated. Suited for steel, stainless steel, cast iron, super-alloys & titanium, hard material.

Specifications

ChipbreakerNone
Coating finishTiAlN
Coating processPVD
Coolant throughNo
Corner radius0.2500
Cutting diameter0.5000
Extension from holder in0.6500
Functional length0.6500
Helix angle30
Included angle degree90
Length of cut0.3700
Manufacturers catalog number47B-5037T8RB06 IN2005
Manufacturer gradeIN2005
Material gradeC2
Maximum depth of cut0.3700
Milling tip full descriptionBall Nose
Milling tip style47B
Milling tip typeBall Nose
Number of flutes4
Overall length0.6500
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Super-alloys & Titanium; Hard Material
Thread sizeT08
Tool materialCarbide
