Ingersoll Cutting Tools
16IRM14NPT Carbide Insert, Grade TT9030, TiAlN - Ingersoll Cutting Tools 5901585
MFR# Ingersoll Cutting Tools-5901585ISO/ANSI# 16IRM14NPTSeries NPT M-Type
$19.38List $24.85
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC3/8
GradeTT9030
MaterialCarbide
CoatingTiAlN
Description
The Ingersoll Cutting Tools 5901585 is a 16IRM14NPT carbide indexable insert, grade TT9030, TiAlN coated. Suited for steel, stainless steel, cast iron.
Specifications
ChipbreakerM
Coating finishTiAlN
Coating processPVD
Corner radius0.0020
Cutting edge to theoretical edge length0.0470
Face of insert to tip centerline0.0350
Included angle60
Inscribed circle in3/8
Insert handRight Hand
Insert materialCarbide
Insert size code16
Insert style16IR
Iso code16IRM14NPT
Manufacturer gradeTT9030
Number of teeth per side1
Pitch (mm)1.81
Primary workpiece materialSteel; Stainless Steel; Cast Iron
Secondary workpiece materialHard Material; Superalloys & Titanium; Non-Ferrous Metal
Thickness0.1430
Thread standardNPT 60 Degree
Thread typeInternal
