Iscar
Indexable Milling Cutters - Iscar 3103492
MFR# 3103492Cat# HP F90AT D2.0-4-.75-22Series HP F90AT
$594.61List $614.00
Save 3%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes4
Description
The Iscar 3103492 indexable milling cutters. Series HP F90AT.
Specifications
Arbor hole diameter in3/4
Compatible insert size codeHP AD 2207
Complete insert compatibilityADCR 2207; ADKT; HP ADCT
Coolant throughNo
Cutter styleHP F90AT-22
Cutting directionRight Hand
Hub diameter1.8900
Insert holding methodClamp; Screw
Lead angle0/90
Manufacturers catalog numberHP F90AT D2.0-4-.75-22
Maximum cutting diameter in2
Maximum depth of cut0.8270
Maximum ramping angle5.00
Number of cutter inserts4
Number of flutes4
Overall height in2
StandardsISO
