Kennametal
RCMK060400 Carbide Insert, Grade KC730, TiN - Kennametal 1163522
MFR# 1163522ISO/ANSI# RCMK060400Series K-LOCK
$19.37List $23.64
Save 18%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/4
GradeKC730
MaterialCarbide
CoatingTiN
Description
The Kennametal 1163522 is a RCMK060400 carbide indexable insert, grade KC730, TiN coated. Suited for steel, stainless steel, superalloys & titanium.
Specifications
ApplicationsProfiling; Turning
ChipbreakerNone
Coating finishTiN
Coating processPVD
Corner radius0.1250
Hole diameter0.0000
Included angle360
Inscribed circle in1/4
Insert handNeutral
Insert height0.3580
Insert holding methodClamp; Pin
Insert length in1/4
Insert materialCarbide
Insert size code23
Insert styleRCMK
Iso codeRCMK060400
Manufacturer gradeKC730
Material gradeP10; P20; M10; M20; S10; S20
Maximum depth of cut0.1250
Msc manufacturer numberRCMK23
Number of cutting edges4
Primary workpiece materialSteel; Stainless Steel; Superalloys & Titanium
RakePositive
Rake angle7
Relief angle5
ShapeRound
Side length0.2500
StandardsRCMK23; RCMK060400
Thickness0.3580
Width in1/4
