Kennametal
RCMK060400 Carbide Insert, Grade K313, WC-Co - Kennametal 1163532
MFR# 1163532ISO/ANSI# RCMK060400Series K-LOCK
$17.05List $20.81
Save 18%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/4
GradeK313
MaterialCarbide
CoatingWC-Co
Description
The Kennametal 1163532 is a RCMK060400 carbide indexable insert, grade K313, WC-Co coated. Suited for non-ferrous metal, superalloys & titanium.
Specifications
ApplicationsProfiling; Turning
ChipbreakerNone
Coating finishWC-Co
Coating processUncoated
Corner radius0.1250
Hole diameter0.0000
Included angle360
Inscribed circle in1/4
Insert handNeutral
Insert height0.3580
Insert holding methodClamp; Pin
Insert length in1/4
Insert materialCarbide
Insert size code23
Insert styleRCMK
Iso codeRCMK060400
Manufacturer gradeK313
Material gradeFine Grain
Maximum depth of cut0.1250
Msc manufacturer numberRCMK23
Number of cutting edges4
Primary workpiece materialNon-Ferrous Metal; Superalloys & Titanium
RakePositive
Rake angle7
Relief angle5
ShapeRound
Side length0.2500
StandardsRCMK23; RCMK060400
Thickness0.3580
Width in1/4
