C - Diamond (Rhombic) 80-Deg 5/8" IC Ceramic Insert, Grade KY3500 - Kennametal 1181992

Kennametal

C - Diamond (Rhombic) 80-Deg 5/8" IC Ceramic Insert, Grade KY3500 - Kennametal 1181992

MFR# 1181992ISO/ANSI# CNGA160612Series KENLOC

$39.05List $46.83 Save 16%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC5/8
ShapeC - Diamond (Rhombic) 80-Deg
GradeKY3500
MaterialCeramic

Description

The Kennametal 1181992 is a ceramic indexable insert, grade KY3500. Suited for cast iron.

Specifications

Ansi insert codeCNGA543
Ansi size code543
Chip breakerFlat Top
Chip breaker operationFlat Top
Clearance codeN
Coating processUncoated
Corner radius in3/64
Cutting edge styleT-Land
Full radiusNo
Grade characteristicsCast Iron (K) - High Wear-Resistance to Moderate Wear-Resistance and Toughness
Hole diameter0.2500
Included angle80
Industry standard numberCNGA543T0820
Inscribed circle in5/8
Insert handNeutral
Insert holding methodClamp; Pin
Insert length0.6346
Insert materialCeramic
Insert shapeC - Diamond (Rhombic) 80-Deg
Insert size code543
Insert styleCNGA
Insert thickness in1/4
Iso insert codeCNGA160612
Iso size code160612
Length range0.6000 - 0.6500
Manufacturers catalog number1181992
Manufacturer gradeKY3500
Material gradeSilicon Nitride
Maximum depth of cut0.0492
Multi use applicationTurning; Facing; Boring
Multi use toolYes
Number of cutting edges4
Primary workpiece materialCast Iron
RakeNegative
Rake angle0
Relief angle0
Side clearanceNegative
StandardsANSI; ISO
Tolerance codeG
Width in5/8
Wiper edgeNo
