Kennametal
CAT50 Collet Chuck - Kennametal 1261783
MFR# 1261783
$236.11List $296.39
Save 20%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Kennametal 1261783 is a CAT50 Collet Chuck.
Specifications
Actuator typeWrench
Balanced to rpm12000
Collet nut diameter1.9690
Collet seriesER32
Collet systemER
Coolant typeThrough-Spindle & DIN Flange
Maximum collet capacity0.7874
Minimum collet capacity0.0800
Nose diameter1.9700
Overall length in8
Projection in4
Shank typeTaper
Taper sizeCAT50
Through coolantYes
