Kennametal
RCMK040300 Carbide Insert, Grade KC5010, AlTiN - Kennametal 1865870
MFR# 1865870ISO/ANSI# RCMK040300Series K-LOCK
$15.89List $19.40
Save 18%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC3/16
GradeKC5010
MaterialCarbide
CoatingAlTiN
Description
The Kennametal 1865870 is a RCMK040300 carbide indexable insert, grade KC5010, AlTiN coated. Suited for steel, stainless steel, cast iron, non-ferrous metal, superalloys & titanium, hard material.
Specifications
ApplicationsProfiling; Turning
ChipbreakerNone
Coating finishAlTiN
Coating processPVD
Corner radius0.0938
Hole diameter0.0000
Included angle360
Inscribed circle in3/16
Insert handNeutral
Insert height0.2510
Insert holding methodClamp; Pin
Insert length in3/16
Insert materialCarbide
Insert size code152
Insert styleRCMK
Iso codeRCMK040300
Manufacturer gradeKC5010
Material gradeP10; P20; M10; M20; K05; K10; K15; K20; N10; N20; S10; S20; H10
Maximum depth of cut0.0938
Msc manufacturer numberRCMK152
Number of cutting edges4
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Superalloys & Titanium; Hard Material
RakePositive
Rake angle7
Relief angle5
ShapeRound
Side length0.1875
StandardsRCMK152; RCMK040300
Thickness in5/16
Width in3/16
