RCMK120800 Carbide Insert, Grade KC5010, AlTiN - Kennametal 1865954

Kennametal

RCMK120800 Carbide Insert, Grade KC5010, AlTiN - Kennametal 1865954

MFR# 1865954ISO/ANSI# RCMK120800Series K-LOCK

$29.27List $35.73 Save 18%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC1/2
GradeKC5010
MaterialCarbide
CoatingAlTiN

Description

The Kennametal 1865954 is a RCMK120800 carbide indexable insert, grade KC5010, AlTiN coated. Suited for steel, stainless steel, cast iron, non-ferrous metal, superalloys & titanium, hard material.

Specifications

ApplicationsProfiling; Turning
ChipbreakerNone
Coating finishAlTiN
Coating processPVD
Corner radius0.2500
Hole diameter0.0000
Included angle360
Inscribed circle in1/2
Insert handNeutral
Insert height0.6540
Insert holding methodClamp; Pin
Insert length in1/2
Insert materialCarbide
Insert size code46
Insert styleRCMK
Iso codeRCMK120800
Manufacturer gradeKC5010
Material gradeP10; P20; M10; M20; K05; K10; K15; K20; N10; N20; S10; S20; H10
Maximum depth of cut0.2500
Msc manufacturer numberRCMK46
Number of cutting edges4
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Superalloys & Titanium; Hard Material
RakePositive
Rake angle7
Relief angle5
ShapeRound
Side length0.5000
StandardsRCMK46; RCMK120800
Thickness0.6540
Width in1/2
