Kennametal
R - Round 5/8" IC Carbide Insert, Grade KCP30, TiN - Kennametal 3753642
MFR# 3753642ISO/ANSI# RNMG150600Series KENLOC
$30.67List $37.43
Save 18%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC5/8
ShapeR - Round
GradeKCP30
MaterialCarbide
CoatingTiN
Description
The Kennametal 3753642 is a carbide indexable insert, grade KCP30, TiN coated. Suited for steel.
Specifications
Ansi insert codeRNMG54
Ansi size code54
Chip breakerRN
Chip breaker operationRoughing; Medium Machining
Clearance codeN
Coating finishTiN
Coating processMTCVD
Corner radius in3/8
Cutting edge styleChamfered; Honed
Full radiusYes
Grade characteristicsSteel (P) - Moderate Wear-Resistance and Toughness to High Toughness; Stainless Steel (M) - Moderate Wear-Resistance and Toughness
Hole diameter0.2500
Included angle360
Industry standard numberRNMG54RN
Inscribed circle in5/8
Insert handNeutral
Insert holding methodClamp; Pin
Insert length in5/8
Insert materialCarbide
Insert shapeR - Round
Insert size code54
Insert styleRNMG
Insert thickness in1/4
Iso insert codeRNMG150600
Iso size code150600
Length range0.6000 - 0.6500
Manufacturers catalog number3753642
Manufacturer gradeKCP30
Material gradeC5; C6
Maximum depth of cut0.0492
Multi use applicationTurning; Facing; Boring
Multi use toolYes
Number of cutting edges8
Primary workpiece materialSteel
RakeNegative
Rake angle0
Relief angle0
Side clearanceNegative
StandardsANSI; ISO
Tolerance codeM
Width in5/8
Wiper edgeNo
