SNMG643 Carbide Insert, Grade KCP40, TiN - Kennametal 3754008

Kennametal

SNMG643 Carbide Insert, Grade KCP40, TiN - Kennametal 3754008

MFR# 3754008ISO/ANSI# SNMG190612Series KENLOC

$48.08List $58.69 Save 18%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC3/4
ShapeS - Square
GradeKCP40
MaterialCarbide
CoatingTiN

Description

The Kennametal 3754008 is a SNMG643 carbide indexable insert, grade KCP40, TiN coated. Suited for steel, stainless steel.

Specifications

Ansi insert codeSNMG643
Ansi size code643
Chip breakerRN
Chip breaker operationRoughing; Medium Machining
Clearance codeN
Coating finishTiN
Coating processMTCVD
Corner radius in3/64
Cutting edge styleChamfered; Honed
Full radiusNo
Grade characteristicsSteel (P) - High Toughness; Stainless Steel (M) - Moderate Wear-Resistance and Toughness
Hole diameter0.3125
Included angle90
Industry standard numberSNMG643RN
Inscribed circle in3/4
Insert handNeutral
Insert holding methodClamp; Pin
Insert length in3/4
Insert materialCarbide
Insert shapeS - Square
Insert size code643
Insert styleSNMG
Insert thickness in1/4
Iso codeSNMG643
Iso insert codeSNMG190612
Iso size code190612
Length range0.7000 - 10.0000
Manufacturers catalog number3754008
Manufacturer gradeKCP40
Material gradeC5; C6
Maximum depth of cut0.0492
Multi use applicationTurning; Facing; Boring
Multi use toolYes
Number of cutting edges8
Primary workpiece materialSteel; Stainless Steel
RakeNegative
Rake angle0
Relief angle0
Side clearanceNegative
StandardsANSI; ISO
Tolerance codeM
Width in3/4
Wiper edgeNo
