Kennametal
Carbide Insert, Grade KCU25, AlTiN - Kennametal 3781264
MFR# 3781264Series A4
$75.57List $92.25
Save 18%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
GradeKCU25
MaterialCarbide
CoatingAlTiN
Description
The Kennametal 3781264 is a carbide indexable insert, grade KCU25, AlTiN coated.
Specifications
Chip breakerGUP
Coating finishAlTiN
Coating processPVD
Corner radius0.0315
Cutting width0.3937
Full radiusNo
Insert handNeutral
Insert materialCarbide
Insert seat size10
Insert size1000
Insert styleA4G
Manufacturer gradeKCU25
Material gradeC2; C6
Maximum depth of cut0.2362
Maximum depth of cut range0.2000 to 0.3000
Measurement typeMetric
Multi use toolNo
Overall length1.1811
RakePositive
