Kennametal
RCGK040300HP Carbide Insert, Grade KCU10 - Kennametal 4050653
MFR# 4050653ISO/ANSI# RCGK040300HPSeries K-LOCK
$15.50List $18.93
Save 18%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC3/16
GradeKCU10
MaterialCarbide
Description
The Kennametal 4050653 is a RCGK040300HP carbide indexable insert, grade KCU10. Suited for steel, stainless steel, cast iron, non-ferrous metal, superalloys & titanium, hard material.
Specifications
ApplicationsProfiling; Turning
ChipbreakerNone
Coating processPVD
Corner radius0.0938
Hole diameter0.0000
Included angle360
Inscribed circle in3/16
Insert handNeutral
Insert height0.2510
Insert holding methodClamp; Pin
Insert length in3/16
Insert materialCarbide
Insert size code152HP
Insert styleRCGK
Iso codeRCGK040300HP
Manufacturer gradeKCU10
Material gradeP10; P20; M10; M20; K05; K20; N10; N20; S10; S20; H10
Maximum depth of cut0.0938
Msc manufacturer numberRCGK152HP
Number of cutting edges4
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Superalloys & Titanium; Hard Material
RakePositive
Rake angle7
Relief angle5
ShapeRound
Side length0.1875
StandardsRCGK152HP; RCGK040300HP
Thickness0.2510
Width in3/16
