RCMK060400 Carbide Insert, Grade KCU10 - Kennametal 4050661

Kennametal

RCMK060400 Carbide Insert, Grade KCU10 - Kennametal 4050661

MFR# 4050661ISO/ANSI# RCMK060400Series K-LOCK

$15.97List $19.49 Save 18%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC1/4
GradeKCU10
MaterialCarbide

Description

The Kennametal 4050661 is a RCMK060400 carbide indexable insert, grade KCU10. Suited for steel, stainless steel, cast iron, non-ferrous metal, superalloys & titanium, hard material.

Specifications

ApplicationsProfiling; Turning
ChipbreakerNone
Coating processPVD
Corner radius0.1250
Hole diameter0.0000
Included angle360
Inscribed circle in1/4
Insert handNeutral
Insert height0.3580
Insert holding methodClamp; Pin
Insert length in1/4
Insert materialCarbide
Insert size code23
Insert styleRCMK
Iso codeRCMK060400
Manufacturer gradeKCU10
Material gradeP10; P20; M10; M20; K05; K20; N10; N20; S10; S20; H10
Maximum depth of cut0.1250
Msc manufacturer numberRCMK23
Number of cutting edges4
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Non-Ferrous Metal; Superalloys & Titanium; Hard Material
RakePositive
Rake angle7
Relief angle5
ShapeRound
Side length0.2500
StandardsRCMK23; RCMK060400
Thickness0.3580
Width in1/4
