Kennametal
SNMM190612RH Carbide Insert, Grade NL300 - Kennametal 5653377
MFR# 5653377ISO/ANSI# CNMG120408
$23.93List $29.21
Save 18%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeC - Diamond (Rhombic) 80-Deg
GradeNL300
MaterialCarbide
Description
The Kennametal 5653377 is a SNMM190612RH carbide indexable insert, grade NL300.
Specifications
Ansi insert codeCNMG432
Ansi size code432
Chip breaker3J
Clearance codeN
Corner radius in1/32
Included angle80
Industry standard numberTCMT3251LF
Inscribed circle in1/2
Insert holding methodClamp; Pin
Insert materialCarbide
Insert shapeC - Diamond (Rhombic) 80-Deg
Insert size code432
Insert styleCNMG
Insert thickness in3/16
Iso codeSNMM190612RH
Iso insert codeCNMG120408
Iso size code120408
Manufacturers catalog number5653377
Manufacturer gradeNL300
Relief angle0
Side clearanceNegative
Tolerance codeM
