Kennametal
#10-32 UNF Powdered Metal Tap, AlCrTiN - Kennametal 5708208
MFR# 5708208Series T692
$55.01List $70.45
Save 21%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes2
Thread size#10-32
CoatingAlCrTiN
Description
The Kennametal 5708208 is a #10-32 UNF Powdered Metal tap with a AlCrTiN finish. 2 flutes.
Specifications
ChamferModified Bottoming
Class of fit2B
Coating finishAlCrTiN
Coolant throughNo
Flute directionRight Hand
Flute styleSlow
Helix angle10
MaterialPowdered Metal
Material applicationNickel Alloy
Neck length0.4400
Number of flutes2
Overall length in2-3/8
Primary workpiece materialHigh-Temp Alloy
Shank diameter0.1940
Tapping depth0.9100
Thread directionRight Hand
Thread length0.4700
Thread limitH3
Thread size in#10-32
Thread standardUNF
