Kennametal
M10x1.5 Metric High-Speed Steel-E Tap, Oxide - Kennametal 6140843
MFR# 6140843
$83.36List $106.92
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes3
CoatingOxide
Description
The Kennametal 6140843 is a Metric High-Speed Steel-E tap with a Oxide finish. 3 flutes.
Specifications
ChamferModified Bottoming
Coating finishOxide
Coolant throughNo
Flute directionRight Hand
Flute styleFast
Helix angle45
MaterialHigh-Speed Steel-E
Neck length in33/64
Number of flutes3
Overall length2.9200
OversizeNo
Primary workpiece materialSteel; Stainless Steel; Cast Iron
Shank diameter0.3810
Shank length1.4090
Square length0.4400
Square size0.2840
Tapping depth1.2600
Thread directionRight Hand
Thread length0.7500
Thread limitD6
Thread size (mm)M10x1.5
Thread standardMetric
