Kennametal
XEPW160520SRD Solid Carbide Insert, Grade KC522M, AlTiN - Kennametal 6187717
MFR# 6187717ISO/ANSI# XEPW160520SRDCat# XEPW160520SRDSeries XEPW
$29.24List $35.69
Save 18%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
ShapeSquare
GradeKC522M
MaterialSolid Carbide
CoatingAlTiN
Description
The Kennametal 6187717 is a XEPW160520SRD solid carbide indexable insert, grade KC522M, AlTiN coated. Suited for steel, stainless steel, cast iron, superalloys & titanium.
Specifications
Ansi codeXEPW160520SRD
Chip breakerD
Coating finishAlTiN
Coating processPVD
Corner radius in5/64
Cutter series compatibility7792VXE16
Cutting edge styleChamfered; Honed
Hole diameter0.2165
Included angle degree90
Inscribed circle0.6610
Inscribed circle range0.6000 to 0.7000
Insert handRight Hand
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeSquare
Insert size16
Insert size code160520
Insert styleXEPW
Iso codeXEPW160520SRD
Length0.6610
Length range0.6500 to 0.7000
Manufacturers catalog numberXEPW160520SRD
Manufacturer gradeKC522M
Material applicationSteel; Stainless Steel; Cast Iron; Superalloys & Titanium
Material gradeC1
Multi use toolYes
Number of cutting edges4
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Superalloys & Titanium
RakePositive
Relief angle20.00
Single or double sided insertSingle
StandardsANSI; ISO
Thickness in7/32
Thickness range0.2000 to 0.2200
Width0.6610
