Kennametal
XDLT120508ERD41 Solid Carbide Insert, Grade KCSM40, TiAlN - Kennametal 6441067
MFR# 6441067ISO/ANSI# XDLT120508ERD41Cat# XDLT120508ERD41Series XDLT
$45.14List $55.10
Save 18%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeSquare
GradeKCSM40
MaterialSolid Carbide
CoatingTiAlN
Description
The Kennametal 6441067 is a XDLT120508ERD41 solid carbide indexable insert, grade KCSM40, TiAlN coated. Suited for steel, stainless steel, superalloys & titanium.
Specifications
Ansi codeXDLT120508ERD41
Chip breakerD41
Coating finishTiAlN
Coating processPVD
Corner radius in1/32
Cutter series compatibility7792VXD12
Cutting edge styleHoned
Hole diameter0.1732
Included angle degree90
Inscribed circle in1/2
Inscribed circle range0.5000 to 0.5100
Insert handRight Hand
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeSquare
Insert size12
Insert size code120508
Insert styleXDLT
Iso codeXDLT120508ERD41
Length in1/2
Length range0.5000 to 0.6000
Manufacturers catalog numberXDLT120508ERD41
Manufacturer gradeKCSM40
Material applicationSteel; Stainless Steel; Superalloys & Titanium
Maximum depth of cut0.3260
Multi use toolYes
Number of cutting edges4
Primary workpiece materialSteel; Stainless Steel; Superalloys & Titanium
RakePositive
Relief angle15.00
Single or double sided insertSingle
StandardsANSI; ISO
Thickness in7/32
Thickness range0.2000 to 0.2200
Width in1/2
