1in" 4-Flute Solid Carbide Ball End Mill, AlTiN - Kennametal 6767777

Kennametal

1in" 4-Flute Solid Carbide Ball End Mill, AlTiN - Kennametal 6767777

MFR# 6767777Cat# H1TE4BN1000R150HASeries H1TEBN..N-L

$763.00List $978.58 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter1in
Flutes4
MaterialSolid Carbide
CoatingAlTiN

Description

The Kennametal 6767777 is a 1in 4-flute Solid Carbide (KCPM15) ball end mill with a AlTiN finish for longer tool life. Suited for steel, stainless steel, cast iron, superalloys & titanium, hard material. 1-1/2in length of cut, 4-1/2in overall length. Series H1TEBN..N-L.

Specifications

Additional informationVersatile Solid Carbide End Mill For Steels, Stainless Steel, Cast Iron, And High Temperature Alloys. Harvi I Te Solid Carbide End Mills Cover A Variety Of Operations, Including Dynamic Milling, And Extreme Ramping Operations. Harvi I Te Solid Carbide E
ChipbreakerNo
Coating finishAlTiN
Coolant throughNo
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Flute typeHelical
Helix angleVariable
Helix styleVariable
Length of cut in1-1/2in
Length typeStandard
Manufacturers catalog numberH1TE4BN1000R150HA
Material gradeKCPM15
Material removal typeRoughing & Finishing
Mill diameter in1in
Neck length0.0000
Nose radius0.5000
Number of flutes4
Overall length in4-1/2in
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Superalloys & Titanium; Hard Material
Reach length1.5000
Shank diameter in1in
Shank typeStraight-Cylindrical
Single or double endSingle
System of measurementFractional Inch
Variable helixYes
Variable indexNo
