1/2in" 4-Flute Solid Carbide Ball End Mill, AlTiN - Kennametal 6767778

Kennametal

1/2in" 4-Flute Solid Carbide Ball End Mill, AlTiN - Kennametal 6767778

MFR# 6767778Cat# H1TE4BN0500R100HBSeries H1TEBN..N-L

$176.43List $226.27 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter1/2in
Flutes4
MaterialSolid Carbide
CoatingAlTiN

Description

The Kennametal 6767778 is a 1/2in 4-flute Solid Carbide (KCPM15) ball end mill with a AlTiN finish for longer tool life. Suited for steel, stainless steel, cast iron, superalloys & titanium, hard material. 1in length of cut, 3in overall length. Series H1TEBN..N-L.

Specifications

Additional informationVersatile Solid Carbide End Mill For Steels, Stainless Steel, Cast Iron, And High Temperature Alloys. Harvi I Te Solid Carbide End Mills Cover A Variety Of Operations, Including Dynamic Milling, And Extreme Ramping Operations. Harvi I Te Solid Carbide E
ChipbreakerNo
Coating finishAlTiN
Coolant throughNo
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Flute typeHelical
Helix angleVariable
Helix styleVariable
Length of cut in1in
Length typeStandard
Manufacturers catalog numberH1TE4BN0500R100HB
Material gradeKCPM15
Material removal typeRoughing & Finishing
Mill diameter in1/2in
Neck length0.0000
Nose radius0.2500
Number of flutes4
Overall length in3in
Primary workpiece materialSteel; Stainless Steel; Cast Iron; Superalloys & Titanium; Hard Material
Reach length1.0000
Shank diameter in1/2in
Shank typeWeldon Flat
Single or double endSingle
System of measurementFractional Inch
Variable helixYes
Variable indexNo
