Kennametal
DFPR060304LCO Carbide Insert, Grade KCU40, TiN - Kennametal 7034247
MFR# 7034247ISO/ANSI# DFPR060304LCOSeries Drill Fix
$24.80List $30.28
Save 18%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
GradeKCU40
MaterialCarbide
CoatingTiN
Description
The Kennametal 7034247 is a DFPR060304LCO carbide indexable insert, grade KCU40, TiN coated.
Specifications
Ansi codeDFPR060304LCO
ChipbreakerLC
Coating finishTiN
Compatible drill styleDFPR
Corner radius0.0160
Included angle degree11
Inscribed circle0.2440
Insert materialCarbide
Insert size06
Insert size code06
Insert styleDFPR
Iso codeDFPR060304LCO
Length0.244
Manufacturer gradeKCU40
Relief angle11
ShapeProprietary
Thickness (mm)2.6
Width0.244
