CNMM120402M-SE PCD Insert, Grade KPD001 - Kyocera TBR01610

Kyocera

CNMM120402M-SE PCD Insert, Grade KPD001 - Kyocera TBR01610

MFR# TBR01610ISO/ANSI# CNMM4305MSEKPD001Series ISOI

$47.40List $68.21 Save 30%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
IC1/2
ShapeDiamond 80
GradeKPD001
MaterialPCD

Description

The Kyocera TBR01610 is a CNMM120402M-SE pcd indexable insert, grade KPD001. Suited for non-ferrous metal, superalloys.

Specifications

Clearance codeN
Coating processUncoated
Corner radius in1/128
Cutting edge styleHoned
Full radiusNo
Hole diameter0.2032
Included angle80degree
Industry standard numberCNMM4305MSEKPD001
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp; Pin
Insert length in1-1/64
Insert materialPCD
Insert shapeDiamond 80
Insert size code4305
Insert styleCNMM
Insert thickness in3/16
Iso codeCNMM120402M-SE
Length range0.5000 - 0.6000
Manufacturers catalog numberTBR01610
Manufacturer gradeKPD001
Material gradeSuper Micrograin
Maximum depth of cut0.1102
Multi use applicationBoring; External Turning; Chamfering; Facing; Internal Facing
Multi use toolYes
Number of cutting edges1
Primary workpiece materialNon-Ferrous Metal; Superalloys
RakeNegative
Relief angle0
Single or multi tippedSingle Tipped
StandardsANSI; ISO
Tip length0.1102
Tolerance codeM
Width in1/2in
Wiper edgeNo
