1/4" 2-Flute Solid Carbide Square End Mill - M.A. Ford. 13625000

MFR# 13625000Series 136

$53.96List $69.21 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Diameter1/4

Flutes2

MaterialSolid Carbide

CoatingBright/Uncoated

Description

The M.A. Ford. 13625000 is a 1/4 2-flute Solid Carbide (Micrograin) square end mill. Suited for aluminum & non-ferrous. 3/4 length of cut, 2-1/2 overall length. Series 136.

Specifications

CentercuttingYes

ChipbreakerNo

Coating finishBright/Uncoated

Coating finish familyBright/Uncoated

Coolant throughNo

Cutting directionRight Hand

End mill materialSolid Carbide

Extended reachNo

Flute directionRight Hand

Flute typeSpiral

Helix angle45

Length of cut in3/4

Length of cut range0.7000 - 0.8000

Length typeExtra Long

Material gradeMicrograin

Mill diameter in1/4

Mill diameter tolerance+0.0000/-0.0020 in

Number of flutes2

Overall length in2-1/2

Primary workpiece materialAluminum & Non-Ferrous

Shank diameter in1/4

Shank diameter toleranceh6

Shank typeStraight

Single or double endSingle

System of measurementFractional Inch

Variable helixNo

Variable indexNo
