3/8" 2-Flute Solid Carbide Square End Mill - M.A. Ford. 13637506

M.A. Ford.

3/8" 2-Flute Solid Carbide Square End Mill - M.A. Ford. 13637506

MFR# 13637506Series 136

$87.41List $112.10 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Diameter3/8
Flutes2
MaterialSolid Carbide
CoatingBright/Uncoated

Description

The M.A. Ford. 13637506 is a 3/8 2-flute Solid Carbide (Micrograin) square end mill. Suited for non-ferrous metal. 1-1/4 length of cut, 3 overall length. Series 136.

Specifications

CentercuttingYes
ChipbreakerNo
Coating finishBright/Uncoated
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Flute typeHelical
Helix angle45
Length of cut in1-1/4
Length of cut range1.2500 - 1.5000
Material gradeMicrograin
Mill diameter in3/8
Mill diameter tolerance+0.000 to -0.003 in
Number of flutes2
Overall length in3
Primary workpiece materialNon-Ferrous Metal
Shank diameter in3/8
Shank diameter toleranceh6
Shank typeStraight-Cylindrical
Variable helixNo
Variable indexNo
