M.A. Ford.
5/64" 2-Flute Solid Carbide Ball End Mill - M.A. Ford. 15007810
MFR# 15007810Series 150
$26.70List $34.24
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Diameter5/64
Flutes2
MaterialSolid Carbide
CoatingBright/Uncoated
Description
The M.A. Ford. 15007810 is a 5/64 2-flute Solid Carbide ball end mill. Suited for hardened materials, cast iron, stainless steel, aluminum & non-ferrous, steel, high-temp alloy. 3/16 length of cut, 1-1/2 overall length. Series 150.
Specifications
CentercuttingYes
ChipbreakerNo
Coating finishBright/Uncoated
Coating finish familyBright/Uncoated
Coolant throughNo
Cutting directionRight Hand
End mill materialSolid Carbide
Extended reachNo
Flute directionRight Hand
Flute typeSpiral
Helix angle30
Length of cut in3/16
Length typeStandard
Material removal typeRoughing & Finishing
Mill diameter in5/64
Mill diameter tolerance+0.0000/-0.0020 in
Nose radius0.0391
Number of flutes2
Overall length in1-1/2
Primary workpiece materialHardened Materials; Cast Iron; Stainless Steel; Aluminum & Non-Ferrous; Steel; High-Temp Alloy
Shank diameter in1/8
Single or double endSingle
System of measurementFractional Inch
Variable helixNo
Variable indexNo
Can't find your exact tool?Send us a part number — we'll cross-reference it.
Dull tools?Regrinding extends tool life and saves cost.
Alternate & equivalent tools
Matched on diameter, flute count, and material. Need a specific brand or coating? Cross-reference this tool.
