Mitee-Bite
Fixturing Clamp - Mitee-Bite 31300
MFR# 31300
$78.86List $93.05
Save 15%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Mitee-Bite 31300 is a mild steel fixturing clamp.
Specifications
Center screw thread size5/8-11
Expansion height1.0600
FeaturesFor Additional Rigidity Install Recessed Dowel Pin in to Flange
Flange diameter2.7360
Flange thickness0.3100
Height above flange1.2500
Holding force10000lb
Holding force lb10000
MaterialMild Steel
Maximum expansion diameter1.6500
Minimum expansion diameter1.1500
Mounting screw thread size10-32
Mount hole diameter2.2000
Number of mount holes3
Overall height1.5600
Thread length below base0.7900
Torque ft lb224.00
