Parlec
HSK63A ER Coolant Collet Collet Chuck - Parlec H63-32ERP406
MFR# H63-32ERP406
$369.65List $464.00
Save 20%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Description
The Parlec H63-32ERP406 is a HSK63A ER Coolant Collet.
Specifications
Actuator typeWrench
Balanced to rpm25000
Collet nut diameter1.9700
Collet seriesER32
Collet systemER
Coolant typeThrough-Spindle
Maximum collet capacity0.7874
Minimum collet capacity0.0787
Nose diameter1.9700
Projection4.0600
Shank typeHollow Taper
Taper sizeHSK63A
Through coolantYes
Tir0.000200
TypeER Coolant Collet
