ProMax

0.4375" 4-Flute Solid Carbide Corner Radius End Mill, AlTiN - ProMax 120-02814

MFR# 120-02814Series 120

$90.80List $116.45 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Flutes4

MaterialSolid Carbide

CoatingAlTiN

Description

The ProMax 120-02814 is a 0.4375 4-flute Solid Carbide (Micrograin) corner radius end mill with a AlTiN finish for longer tool life. 1 length of cut. Series 120.

Specifications

CentercuttingYes

ChipbreakerNo

Coating finishAlTiN

Corner radius0.0200

Cutting directionRight Hand

End mill materialSolid Carbide

End typeCorner Radius

Extended reachNo

Flute directionRight Hand

Helix angle40

Length of cut in1

Length typeRegular

Material gradeMicrograin

Maximum helix angle40

Mill diameter0.4375

Mill diameter frac in7/16

Mill diameter tolerance+0.000000 to -0.003000 in

Number of flutes4

Shank diameter in7/16

Shank diameter tolerance-0.0001/-0.0004 in

Shank typeStraight-Cylindrical

Single or double endSingle

Can't find your exact tool?Send us a part number — we'll cross-reference it. Dull tools?Regrinding extends tool life and saves cost.

Alternate & equivalent tools

Matched on diameter, flute count, and material. Need a specific brand or coating? Cross-reference this tool.
