Sandvik Coromant
N123K2-0714-RO 1125 Solid Carbide Insert, TiAlN - Sandvik Coromant 5736951
MFR# 5736951ISO/ANSI# N123K2-0714-RO 1125Cat# N123K2-0714-RO 1125Series CoroCut 1-2
$62.23List $79.81
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
MaterialSolid Carbide
CoatingTiAlN
Description
The Sandvik Coromant 5736951 is a N123K2-0714-RO 1125 solid carbide indexable insert, TiAlN coated.
Specifications
Chip breakerRO
Coating finishTiAlN
Coating processPVD
Corner radius0.1406
Cutting height0.1713
Cutting width0.2810
Insert handNeutral
Insert materialSolid Carbide
Insert seat sizeK
Insert sizeK2
Insert styleN123x2
Insert thickness0.1713
Iso codeN123K2-0714-RO 1125
Manufacturers catalog numberN123K2-0714-RO 1125
Maximum depth of cut0.8500
Maximum depth of cut range0.3000 to 1.0000
Minimum corner radius0.1406
Multi use toolYes
Overall length0.9860
Overall width0.2810
RakePositive
