R215.44-15T308M-WH 4030 Solid Carbide Insert, Grade 4030, TiCN - Sandvik Coromant 5742714

Sandvik Coromant

R215.44-15T308M-WH 4030 Solid Carbide Insert, Grade 4030, TiCN - Sandvik Coromant 5742714

MFR# 5742714ISO/ANSI# R215.44-15T308M-WH 4030Cat# R215.44-15T308M-WH 4030Series R215.44

$26.28List $33.71 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
ShapeParallelogram
Grade4030
MaterialSolid Carbide
CoatingTiCN

Description

The Sandvik Coromant 5742714 is a R215.44-15T308M-WH 4030 solid carbide indexable insert, grade 4030, TiCN coated. Suited for steel, cast iron.

Specifications

Ansi codeR215.44-15T308M-WH 4030
Chip breakerWH
Coating finishTiCN
Coating processCVD
Corner radius in1/32
Cutting edge styleCorner Rounded
Hole diameter0.1575
Included angle degree90
Inscribed circle0.3740
Inscribed circle range0.3500 to 0.4000
Insert handRight Hand
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeParallelogram
Insert size15
Insert size code15T308
Insert styleR215.44
Iso codeR215.44-15T308M-WH 4030
Length0.5906
Length range0.5000 to 0.6000
Manufacturers catalog numberR215.44-15T308M-WH 4030
Manufacturer grade4030
Material applicationSteel; Cast Iron
Maximum depth of cut0.5906
Multi use toolYes
Number of cutting edges2
Primary workpiece materialSteel; Cast Iron
RakePositive
Single or double sided insertSingle
StandardsANSI; ISO
Thickness in5/32
Thickness range0.1500 to 0.1750
Width0.3740
