R215.44-15T308M-WL 235 Solid Carbide Insert, Grade 235, TiCN - Sandvik Coromant 5742760

Sandvik Coromant

R215.44-15T308M-WL 235 Solid Carbide Insert, Grade 235, TiCN - Sandvik Coromant 5742760

MFR# 5742760ISO/ANSI# R215.44-15T308M-WL 235Cat# R215.44-15T308M-WL 235Series R215.44

$26.15List $33.53 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
ShapeParallelogram
Grade235
MaterialSolid Carbide
CoatingTiCN

Description

The Sandvik Coromant 5742760 is a R215.44-15T308M-WL 235 solid carbide indexable insert, grade 235, TiCN coated. Suited for steel, stainless steel.

Specifications

Ansi codeR215.44-15T308M-WL 235
Chip breakerWL
Coating finishTiCN
Coating processCVD
Corner radius in1/32
Cutting edge styleCorner Rounded
Hole diameter0.1575
Included angle degree90
Inscribed circle0.3740
Inscribed circle range0.3500 to 0.4000
Insert handRight Hand
Insert holding methodScrew
Insert materialSolid Carbide
Insert shapeParallelogram
Insert size15
Insert size code15T308
Insert styleR215.44
Iso codeR215.44-15T308M-WL 235
Length0.5906
Length range0.5000 to 0.6000
Manufacturers catalog numberR215.44-15T308M-WL 235
Manufacturer grade235
Material applicationSteel; Stainless Steel
Maximum depth of cut0.5906
Multi use toolYes
Number of cutting edges2
Primary workpiece materialSteel; Stainless Steel
RakePositive
Single or double sided insertSingle
StandardsANSI; ISO
Thickness in5/32
Thickness range0.1500 to 0.1750
Width0.3740
