Sandvik Coromant

0.1181" 3-Flute Solid Carbide Square End Mill, TiAlN - Sandvik Coromant 5742903

MFR# 5742903Series CoroMill Plura

$118.73List $152.28 Save 22%

In stock - ships in 1-3 business days

Request a quote

Fast sourcing
Regrinding available
20+ yrs expertise

Flutes3

MaterialSolid Carbide

CoatingTiAlN

Description

The Sandvik Coromant 5742903 is a 0.1181 3-flute Solid Carbide (1620) square end mill with a TiAlN finish for longer tool life. 0.3937 length of cut. Series CoroMill Plura.

Specifications

CentercuttingYes

ChipbreakerNo

Coating finishTiAlN

Cutting directionRight Hand

End mill materialSolid Carbide

Extended reachNo

Flute directionRight Hand

Flute typeHelical

Helix angle50

Length of cut0.3937

Length of cut range0.3000 - 0.5000

Length typeStandard

Material grade1620

Mill diameter0.1181

Mill diameter toleranceh9

Number of flutes3

Overall length (mm)57

Reach length0.8268

Shank diameter0.2362

Variable helixNo

Variable indexNo
