Sandvik Coromant
TCMT110304PM1525 Cermet Insert, Grade 1525, TiCN - Sandvik Coromant 5752559
MFR# 5752559ISO/ANSI# TCMT110304PM1525Series CoroTurn 107
$14.90List $19.12
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/4
ShapeTriangle
Grade1525
MaterialCermet
CoatingTiCN
Description
The Sandvik Coromant 5752559 is a TCMT110304PM1525 cermet indexable insert, grade 1525, TiCN coated.
Specifications
Chip breakerT
Clearance codeC
Coating finishTiCN
Coating processPVD
Corner radius in1/64
Hole diameter0.1102
Included angle60
Inscribed circle in1/4
Insert handNeutral
Insert holding methodScrew
Insert length0.4228
Insert materialCermet
Insert shapeTriangle
Insert size code221
Insert styleTCMT
Insert thickness in1/8
Iso codeTCMT110304PM1525
Length range0.4000 - 0.5000
Manufacturers catalog number5752559
Manufacturer grade1525
Maximum depth of cut0.4071
Relief angle7
Tolerance codeM
