Sandvik Coromant
CNMG190612SM1125 Carbide Insert, Grade 1125, TiAlN - Sandvik Coromant 6066606
MFR# 6066606ISO/ANSI# CNMG190612SM1125Series T-Max P
$43.03List $55.19
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC3/4
ShapeDiamond
Grade1125
MaterialCarbide
CoatingTiAlN
Description
The Sandvik Coromant 6066606 is a CNMG190612SM1125 carbide indexable insert, grade 1125, TiAlN coated.
Specifications
Chip breakerG
Clearance codeN
Coating finishTiAlN
Coating processPVD
Corner radius in3/64
Hole diameter0.3122
Included angle80
Inscribed circle in3/4
Insert handNeutral
Insert holding methodClamp; Pin
Insert length0.7614
Insert materialCarbide
Insert shapeDiamond
Insert size code643
Insert styleCNMG
Insert thickness in1/4
Iso codeCNMG190612SM1125
Length range0.7000 - 10.0000
Manufacturers catalog number6066606
Manufacturer grade1125
Maximum depth of cut0.7142
Relief angle0
Tolerance codeM
