CNGG 12 04 01-SGF 1105 Carbide Insert, Grade 1105, TiAlN2 - Sandvik Coromant 6851263
MFR# 6851263ISO/ANSI# CNGG 12 04 01-SGF 1105Series T-Max P
$25.92List $33.25
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC1/2
ShapeDiamond
Grade1105
MaterialCarbide
CoatingTiAlN2
Description
The Sandvik Coromant 6851263 is a CNGG 12 04 01-SGF 1105 carbide indexable insert, grade 1105, TiAlN2 coated. Suited for stainless steel.
Specifications
Chip breakerSGF
Clearance codeN
Coating finishTiAlN2
Coating processPVD
Corner radius0.0039
Cutting edge styleSharp
Hole diameter0.2030
Included angle80
Inscribed circle in1/2
Insert handNeutral
Insert holding methodClamp; Pin
Insert materialCarbide
Insert shapeDiamond
Insert size code43.3
Insert styleCNGG
Insert thickness in3/16
Iso codeCNGG 12 04 01-SGF 1105
Manufacturer grade1105
Maximum depth of cut (mm)12.78
Number of cutting edges4
Primary workpiece materialStainless Steel
Relief angle0
Secondary workpiece materialSuperalloy; Titanium
Tolerance codeG
Wiper edgeNo
