N123H1-0150-RO 1125 Carbide Insert, Grade 1125, TiAlN - Sandvik Coromant 7582576

Sandvik Coromant

N123H1-0150-RO 1125 Carbide Insert, Grade 1125, TiAlN - Sandvik Coromant 7582576

MFR# 7582576ISO/ANSI# N123H1-0150-RO 1125Series CoroCut 1-2

$37.18List $47.68 Save 22%
In stock - ships in 1-3 business days
Request a quote
  • Fast sourcing
  • Regrinding available
  • 20+ yrs expertise
Grade1125
MaterialCarbide
CoatingTiAlN

Description

The Sandvik Coromant 7582576 is a N123H1-0150-RO 1125 carbide indexable insert, grade 1125, TiAlN coated. Suited for steel, stainless steel, superalloys & titanium.

Specifications

ApplicationsProfiling; Turning
ChipbreakerRO
Coating finishTiAlN
Coating processPVD
Corner radius0.0296
Hole diameter0.0000
Included angle360
Inscribed circle0.0591
Insert handNeutral
Insert holding methodClamp
Insert length in3/16
Insert materialCarbide
Insert size code0150
Insert styleN123H1
Iso codeN123H1-0150-RO 1125
Manufacturer grade1125
Material gradeM25; S25
Maximum depth of cut0.0197
Msc manufacturer numberN123H1-0150-RO 1125
Number of cutting edges1
Primary workpiece materialSteel; Stainless Steel; Superalloys & Titanium
RakePositive
Rake angle10
Relief angle7
ShapeRectangle
Side length0.1872
StandardsN123H1-0150-RO 1125; N123H1-0150-RO 1125
Width0.0591
