Sandvik Coromant
CNMM 19 06 12-PR 4415 Carbide Insert, Grade 4415, TiCN - Sandvik Coromant 7859204
MFR# 7859204ISO/ANSI# CNMM 19 06 12-PR 4415Cat# CNMM 643-PR 4415Series T-Max P
$45.64List $58.54
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
ShapeDiamond
Grade4415
MaterialCarbide
CoatingTiCN
Description
The Sandvik Coromant 7859204 is a CNMM 19 06 12-PR 4415 carbide indexable insert, grade 4415, TiCN coated. Suited for steel.
Specifications
Chip breakerPR
Clearance codeN
Coating finishTiCN
Coating processCVD
Corner radius0.0469
Hole diameter0.3120
Included angle80
Inscribed circle0.3120
Insert handNeutral
Insert holding methodClamp; Screw
Insert materialCarbide
Insert shapeDiamond
Insert size code1906
Insert styleCNMM
Insert thickness in1/4
Iso codeCNMM 19 06 12-PR 4415
Manufacturers catalog numberCNMM 643-PR 4415
Manufacturer grade4415
Number of cutting edges2
Primary workpiece materialSteel
Relief angle0
Secondary workpiece materialCast Iron
Tolerance codeM
Wiper edgeNo
