Sandvik Coromant
CNMM 16 06 08-PR 4425 Carbide Insert, Grade 4425, TiCN - Sandvik Coromant 7860735
MFR# 7860735ISO/ANSI# CNMM 16 06 08-PR 4425Cat# CNMM542PR4425Series T-Max P
$30.74List $39.42
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC5/8
ShapeDiamond
Grade4425
MaterialCarbide
CoatingTiCN
Description
The Sandvik Coromant 7860735 is a CNMM 16 06 08-PR 4425 carbide indexable insert, grade 4425, TiCN coated.
Specifications
Chip breakerM
Clearance codeN
Coating finishTiCN
Coating processCVD
Corner radius0.0313
Included angle80
Inscribed circle in5/8
Insert handNeutral
Insert holding methodClamp; Screw
Insert materialCarbide
Insert shapeDiamond
Insert size code1606
Insert styleCNMM
Insert thickness in1/4
Iso codeCNMM 16 06 08-PR 4425
Manufacturers catalog numberCNMM542PR4425
Manufacturer grade4425
Relief angle0
Tolerance codeM
