Sandvik Coromant
CNMG 19 06 08-MR 4425 Carbide Insert, Grade 4425, TiCN - Sandvik Coromant 8019638
MFR# 8019638ISO/ANSI# CNMG190608Cat# CNMG 19 06 08-MR 4425Series CNMG-MR (ISO P)
$45.72List $58.64
Save 22%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
IC3/4
ShapeC - Diamond (Rhombic) 80-Deg
Grade4425
MaterialCarbide
CoatingTiCN
Description
The Sandvik Coromant 8019638 is a CNMG 19 06 08-MR 4425 carbide indexable insert, grade 4425, TiCN coated. Suited for steel.
Specifications
Ansi insert codeCNMG642
Ansi size code642
Chip breakerMR
Chip breaker operationRoughing; Medium Machining
Clearance codeN
Coating finishTiCN
Coating processCVD
Corner radius0.0313
Grade characteristicsSteel (P) - High Wear-Resistance to Moderate Wear-Resistance and Toughness
Inscribed circle in3/4
Insert handNeutral
Insert holding methodClamp; Screw
Insert materialCarbide
Insert shapeC - Diamond (Rhombic) 80-Deg
Insert size code1906
Insert styleCNMG
Insert thickness in1/4
Iso codeCNMG 19 06 08-MR 4425
Iso insert codeCNMG190608
Iso size code190608
Manufacturers catalog numberCNMG 19 06 08-MR 4425
Manufacturer grade4425
Primary workpiece materialSteel
Relief angle0
Side clearanceNegative
Tolerance codeM
