CP-B1208D-M5 2025 Carbide Insert, Grade 2025, TiCN - Sandvik Coromant 8232387
MFR# 8232387ISO/ANSI# CP-B1208D-M5 2025Cat# CP-B1208D-M5 2025Series CoroTurn Prime
$33.96List $37.10
Save 8%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
ShapeIrregular
Grade2025
MaterialCarbide
CoatingTiCN
Description
The Sandvik Coromant 8232387 is a CP-B1208D-M5 2025 carbide indexable insert, grade 2025, TiCN coated. Suited for stainless steel.
Specifications
Chip breakerM5
Coating finishTiCN
Coating processCVD
Corner radius0.0315
Hole diameter0.2030
Inscribed circle0.4724
Insert handNeutral
Insert holding methodScrew; Clamp
Insert materialCarbide
Insert shapeIrregular
Insert size code1208
Insert styleCP-B
Insert thickness0.2362
Iso codeCP-B1208D-M5 2025
Manufacturers catalog numberCP-B1208D-M5 2025
Manufacturer grade2025
Number of cutting edges8
Primary workpiece materialStainless Steel
RakePositive
Rake angle7
Relief angle0
Stocking categoryDirect Ship
Wiper edgeNo
