Seco
Carbide Insert, Grade F40M, TiAlN - Seco 02880962
MFR# 02880962Series MP16
$200.46List $206.28
Save 2%
In stock - ships in 1-3 business days
Request a quote
- Fast sourcing
- Regrinding available
- 20+ yrs expertise
Flutes6
GradeF40M
CoatingTiAlN
Description
The Seco 02880962 is a carbide indexable insert, grade F40M, TiAlN coated. Suited for steel, stainless steel, non-ferrous metal, superalloys & titanium, hard material.
Specifications
Chamfer angle45degree
ChipbreakerM05
Coating finishTiAlN
Coating processPVD
Coolant throughNo
Corner radius0.0000
Cutting width0.6460in
Extension from holder (mm)23.80
Functional length0.9250
Included angle degree90
Insert handRight Hand
Insert size16009C90Z6
Lead angle45
Length of cut0.2360in
Manufacturers catalog number02880962
Manufacturer gradeF40M
Material gradeP10; P20; P30; P40; P50; N10; N20; M10; M20; M30; M40; S10; S20
Maximum depth of cut0.2360
Milling tip full descriptionMP16-16009C90Z6-M05
Milling tip styleMP16
Milling tip typeChamfer
Number of flutes6
Overall length0.9250in
Primary workpiece materialSteel; Stainless Steel; Non-Ferrous Metal; Superalloys & Titanium; Hard Material
StandardsANSI
Tool materialCarbide
